MRCOOL Signature MGM80SE090C5A 80% AFUE Multi-Position Multi-Speed Natural Gas Furnace with 21" Cabinet - 90,000 BTU

When harsh winter weather strikes, nothing compares to the warmth and safety a powerful reliable gas furnace can provide. While furnace heating technology has been around for decades, not all systems are created equally. Some are definitely better than others. One of the best on the market is the MRCOOL single stage, 80% AFUE gas furnace. This system can be installed upflow or horizontal, and is designed to operate for decades, provide powerful heating capability, and best of all, keep your heating bill affordable at the same time. It does the latter via its 80% AFUE energy efficiency rating. That mark of quality ensures 80% of every dollar you spend on heating fuel gets turned into real, effective heat for your home.

Key Features
Removable floor base for bottom return air
Easily removable slide out blower design
Left or right utility connections
Zero step horizontal conversion
Aluminized steel inshot burners for smooth ignition
Multi-speed high efficiency (constant torque) blower motor
AHRI Certified
Aluminized steel tapered crimped non-welded clam shell heat exchanger design
Heating efficiency of 80% AFUE
Registered 10-year parts warranty
Compact 33" height
Rotatable draft inducer for venting flexibility

Product Dimensions    21"W x 28 3/8"D x 33"H
Product Weight    152 lbs
Unit Type    Gas Furnace
AFUE    80%
CFM    2060
Tonnage    5
Heating Capacity    88,000 BTU
Fuel Type    Natural Gas
BTU Input    88,000
BTU Output    70,400
Voltage    Requires a minimum of 120V/60HZ/15A
Phase    1
Cycle    60
Stage    Single
Max Fuse Breaker    15
Min Circuit Ampacity    10.9
Color    Gray
Full Load    10.9
Number of Burners    8
Gas Connection Size    0.5
Blower Motor Type    ECM
Blower Motor HP    1
Blower Motor Speeds    5 Speed
Blower Motor RPM    1200-2060
Heat Exchanger Type    Aluminized steel
Ignition Type    Silicon Nitride Ignitor
Vent Connector    4 inch
Certifications    CSA
AHRI
Warranty    Registered 10 Year Parts Warranty
Restricted States    Yes (California)
